WOOD INSERTS

OAKDALE™ SERIES

The Napoleon Oakdale™ Series wood burning inserts are available with contemporary and more traditional styling options to match any décor. Four stainless steel secondary air tubes supercharge the fuel-burning process and generate a beautiful display of flames. Complete with a removable painted black log retainer and a heat circulating blower, this wood burning insert is the perfect heating solution.



Available in 26-inch.

BROCHURE

MANUAL

SPECSHEET

OAKDALE™ EPI3T

BROCHURE

MANUAL

SPECSHEET

OAKDALE™ EPI3TN

BROCHURE

MANUAL

SPECSHEET

OAKDALE™ EPI3C

BROCHURE

MANUAL

SPECSHEET

OAKDALE™ EPI3T

Fuel Type: Wood

View Type: Single Sided

KEY SERIES FEATURES:

  • Up to 55,000 BTU's

  • EPA Certified

  • Presidents limited lifetime warranty

  • Black traditional fireplace insert

  • Largest ceramic glass viewing area in the industry

  • Full refractory lined firebox

  • Effective airwash

OAKDALE™ EPI3C

Fuel Type: Wood

View Type: Single Sided

KEY SERIES FEATURES:

  • Up to 55,000 BTU's

  • EPA Certified

  • Presidents limited lifetime warranty

  • Contemporary fireplace insert

  • Largest ceramic glass viewing area in the industry

  • Full refractory lined firebox

  • Effective airwash

OAKDALE™ EPI3TN

Fuel Type: Wood

View Type: Single Sided

KEY SERIES FEATURES:

  • Up to 55,000 BTU's

  • EPA Certified

  • Presidents limited lifetime warranty

  • Majolica brown traditional fireplace insert

  • Largest ceramic glass viewing area in the industry

  • Full refractory lined firebox

  • Effective airwash



1/1

S SERIES INSERTS

The S-Series is the perfect solution for those looking for EPA 2020 certified wood burning technology in an insert with a clean and contemporary look. Best in class features include extremely long burn times, heavy duty firebox top and full width ash lip and base to protect your floor. A dual blower system comes included with the S-Series to ensure optimal comfort.



Available in 20 & 25-inch.

S20I

MANUAL

SPECSHEET

S25I

MANUAL

SPECSHEET

S20I

Fuel Type: Wood

View Type: Single Sided

KEY SERIES FEATURES:

  • Up to 65,000 BTU

  • 1.9 cu. ft. firebox capacity

  • Burn time: 8 hours

  • Weighted average emissions rate: 2.25 g/hr

  • Weighted average overall efficiency: 72%

  • Tested to 2020 cord wood requirements

  • Hidden hinges and extra large glass viewing area

  • Contemporary wood stove complete with contemporary cast door and cast pedestal base

  • Minimum fireplace opening: 25 7/8"W x 22"H x 14"D

  • Dual blower system included

S25I

Fuel Type: Wood

View Type: Single Sided

KEY SERIES FEATURES:

  • Up to 70,000 BTU

  • 2.5 cu. ft. firebox capacity

  • Burn time: 16 hours

  • Weighted average emissions rate: 1.3 g/hr

  • Weighted average overall efficiency: 76%

  • Tested and certified to EPA 2020 cord wood requirements

  • Heavy duty 5/16" firebox top

  • Ceramic fiber baffle system

  • Hidden hinges and extra large glass viewing area

  • Contemporary medium sized wood insert complete with cast door

  • Dual blower system included



1/1

CLYDESDALE

TruHybrid Efficiency

Clean-burning, highly efficient, and easy to operate, the Clydesdale uses our TruHybrid™ technology. Engage the catalyst and turn your stove down for slow and efficient overnight burns.

Open view of the fire

The Clydesdale’s large open window lets you see as much fire as possible. Enjoy the ambiance of a fireplace and the efficiency of HearthStone.

Soapstone firebox

Burn up to 24 inch logs in the soapstone lined firebox. Soapstone retains the maximum heat from your fire and radiates steady warmth as your insert burns.

EPA 2020

A new low emission standard for solid fuel heaters takes effect in 2020.

TruHybrid™

Ultra Clean Combustion Systems

All of our wood stoves exceed 2020 EPA standards so you can be sure they burn clean today and for many years to come.

SPECIFICATIONS:

  • Blower: Included

  • BTU: Available Soon

  • Finish: Brown Enamel, Matte Black

  • Firebox Capacity: Available Soon

  • Flue Exit Diameter: Available Soon

  • Flue Exit Location: Available Soon

  • Heats up to: Available Soon

  • Maximum Log Length: Available Soon

  • Stove Type: Wood Fireplace Insert

  • Weight: 550 lbs

ACCESSORIES:

  • Surround Extension: 94-5990010

  • Surround Base Caps: 94-5970610/20

  • Mantel Shield: 94-79700

INSTALLATION:

Minimum Fireplace Opening:
32 1⁄2″ Width* x 23 1⁄4″ Height* x 13″ Depth



* Hearth may taper to 27″ Width x 21″ Height at the back wall



1/1

GREEN MOUNTAIN INSERT 70

Flush cast iron design
The cast iron front of the GMi70 is designed to fit flush with your hearth for a clean and elegant look.

Soapstone firebox
Burn up to 20 inch logs in the soapstone lined firebox. Soapstone retains the maximum heat from you fire and radiates steady warmth as your insert burns.

Simple operation
Our non-catalytic wood insert is easy to use. A single lever air control lets you burn hot and fast or low and slow to keep warm through the night.

EPA 2020

A new low emission standard for solid fuel heaters takes effect in 2020.

SPECIFICATIONS:

  • Blower: Included

  • BTU: Up to 70,000

  • Efficiency: 69% HHV

  • EPA Certified: 1.54 g/hr

  • Finish: Matte Black, Brown Enamel

  • Firebox Capacity: 2.4 cu ft

  • Flue Exit Diameter: 6

  • Flue Exit Location: Top

  • HeatLife: 10 Hours of heat

  • Heats up to: 2,000 sq ft

  • Maximum Log Length: 20″

  • Stove Type: Wood Fireplace Insert

ACCESSORIES:

  • Steel Surround: 94-5950110

  • Surround Lower Panel: 94-5950519

  • Surround Extension: 94-5950010

  • Outside Air Adapter Kit: 94-53500

  • Fire Screen Insert: 94-59500

  • Linear Hook-Up Collar: 94-67500

CLEARANCES:

  • To combustible mantel from bottom of insert: 50”

  • To side trim from side of insert body: 9”

  • To side wall from side of insert body: 16”



1/1
